Bearing No. |
Dimensions |
Load ratings |
|||||||||
d |
D |
B |
C |
dk |
r1 min |
r2 min |
α |
Dynamic |
Static |
||
mm |
kN |
||||||||||
GE4E |
|
4 |
12 |
5 |
3 |
8 |
0.3 |
0.3 |
16 |
2 |
10 |
GE5E |
|
5 |
14 |
6 |
4 |
10 |
0.3 |
0.3 |
13 |
3.4 |
17 |
GE6E |
|
6 |
14 |
6 |
4 |
10 |
0.3 |
0.3 |
13 |
3.4 |
17 |
GE8E |
|
8 |
16 |
8 |
5 |
13 |
0.3 |
0.3 |
15 |
5.5 |
27 |
GE10E |
|
10 |
19 |
9 |
6 |
16 |
0.3 |
0.3 |
12 |
8.1 |
40 |
GE12E |
|
12 |
22 |
10 |
7 |
18 |
0.3 |
0.3 |
10 |
10 |
53 |
GE15ES |
GE15ES 2RS |
15 |
26 |
12 |
9 |
22 |
0.3 |
0.3 |
8 |
16 |
84 |
GE17ES |
GE17ES 2RS |
17 |
30 |
14 |
10 |
25 |
0.3 |
0.3 |
10 |
21 |
106 |
GE20ES |
GE20ES 2RS |
20 |
35 |
16 |
12 |
29 |
0.3 |
0.3 |
9 |
30 |
146 |
GE25ES |
GE25ES 2RS |
25 |
42 |
20 |
16 |
35.5 |
0.6 |
0.6 |
7 |
48 |
240 |
GE30ES |
GE30ES 2RS |
30 |
47 |
22 |
18 |
40.7 |
0.6 |
0.6 |
6 |
62 |
310 |
GE35ES |
GE35ES 2RS |
35 |
55 |
25 |
20 |
47 |
0.6 |
1 |
6 |
79 |
399 |
GE40ES |
GE40ES 2RS |
40 |
62 |
28 |
22 |
53 |
0.6 |
1 |
7 |
99 |
495 |
GE45ES |
GE45ES 2RS |
45 |
68 |
32 |
25 |
60 |
0.6 |
1 |
7 |
127 |
637 |
GE50ES |
GE50ES 2RS |
50 |
75 |
35 |
28 |
66 |
0.6 |
1 |
6 |
156 |
780 |
GE60ES |
GE60ES 2RS |
60 |
90 |
44 |
36 |
80 |
1 |
1 |
6 |
245 |
1220 |
GE70ES |
GE70ES 2RS |
70 |
105 |
49 |
40 |
92 |
1 |
1 |
6 |
313 |
1560 |
GE80ES |
GE80ES 2RS |
80 |
120 |
55 |
45 |
105 |
1 |
1 |
6 |
400 |
2000 |
GE90ES |
GE90ES 2RS |
90 |
130 |
60 |
50 |
115 |
1 |
1 |
5 |
488 |
2440 |
GE100ES |
GE100ES 2RS |
100 |
150 |
70 |
55 |
130 |
1 |
1 |
7 |
607 |
3030 |
GE110ES |
GE110ES 2RS |
110 |
160 |
70 |
55 |
140 |
1 |
1 |
6 |
654 |
3270 |
GE120ES |
GE120ES 2RS |
120 |
180 |
85 |
70 |
160 |
1 |
1 |
6 |
950 |
4750 |
GE140ES |
GE140ES 2RS |
140 |
210 |
90 |
70 |
180 |
1 |
1 |
7 |
1070 |
5350 |
GE160ES |
GE160ES 2RS |
160 |
230 |
105 |
80 |
200 |
1 |
1 |
8 |
1360 |
6800 |
GE180ES |
GE180ES 2RS |
180 |
260 |
105 |
80 |
225 |
1.1 |
1.1 |
6 |
1530 |
7650 |
GE200ES |
GE200ES 2RS |
200 |
290 |
130 |
100 |
250 |
1.1 |
1.1 |
7 |
2120 |
10600 |
GE220ES |
GE220ES 2RS |
220 |
320 |
135 |
100 |
275 |
1.1 |
1.1 |
8 |
2320 |
11600 |
GE240ES |
GE240ES 2RS |
240 |
340 |
140 |
100 |
300 |
1.1 |
1.1 |
8 |
2550 |
12700 |
